QC1500 Asphalt mixing plant
Configuration file
Site map for your reference
Add: No. 1 Building , 697 Linding Road, Shangcheng District, Hangzhou city, China.
Email: george@icomworld.cn / sales_chinamachine@yeah.net
Phone number: +86 15088721280 Mr. George (Manager Director)
QC1500 Asphalt Mixing Plant Standard Operation Condition
Equipment Name: Asphalt mixing plants
Mode： QC1500
Rated production capacity： 100-120t/h
Rated working condition： Asphalt mix is medium grain size (Ac20)
Aggregate Specification Pass through 40mmscreen： Pass through 3mm screen： Dryer drum outlet temperature： Ambient atmospheric pressure： Ambient temperature： Aggregate density： Aggregate moisture content： Aggregate specific heat： Powder content： Asphalt content： fuel calorific value： Heavy oil： Diesel： |
100% 40% 160℃ 760 mmHg 20℃ 1650 kg/m3 ≤ 5% 0.21 Kcal/kg℃ 5% 5%
9,850 Kcal/kg 10,500 Kcal/kg |
Electrical Design | |
Single phase 220v ,Three phase 380v ,frequency 50HZ | |
Emission standards: | |
Dust collection emission content for filter | ≤ 50mg/Nm3 (Rated condition) |
Mixer part sealing aprts and negative pressure suction | reliable and internatinal standards |
Emission Blackness | Reaching Lingman I |
Environmental noise | ≤80dB |
Indoor of control noise | ≤70dB |
Configuration list of QC1500 asphalt mixing plant
1 | Model | QC1500 asphalt mixing plant | 数量 QTY |
2 | Structure | Modular structure of h-beam, can form of containers, forced intermittent | |
3 | Capacity | 100-120t/h standard operating condition | |
4 | Attached documentation | Date-based map/electric circuit diagram /operating manual | |
5 | Standard electrical | Three-phase 380v,50HZ | |
6 | Scope of supply | Area: 35m×30m |
China Machinery Equipment Co., Ltd ( CMEC) is the leading Chinese construction machinery manufacture and supplier, located in Hangzhou City. Since established in year 2005 , we engaged in the solution of complete sets of asphalt road machinery, Construction machinery, special vehicles and equipment to our customers. Based on the advantage of XCMG, SANY, SINOTRUK etc.which are the Top Chinese construction machinery manufacturers, we continually supply top Chinese construction machinery enterprises and their products to international markets, such as SANY, ZOOMLION, LIUGONG etc.
With so many years of experience, we have a high level of expertise and capability in the field of mechanical equipment. After achieving many successful cases, we stand in the middle of many excellent competitors around the world, build a professional management operation system and professional international sales team, so that we can ensure that orders are converted into mechanical equipment used by customers, successfully export to more than 60 countries and regions around the world.
