PPGISteel Prepainted Galvanized
L/CT/T
roduct Overview & Key Features:
Produced by applying organic coatings over a hot-dip galvanized steel substrate (GI) through continuous coil coating, baking, and curing.
Aesthetic Appeal & Color Retention: Wide spectrum of RAL colors, metallic, textured, and matte finishes with high gloss retention.
Multi-Layer Shielding: Chemical conversion treatment, anti-corrosion primer, and durable topcoat prevent peeling, chalking, and blistering.
Processing Flexibility: High coating flexibility ($2T$–$3T$ bend capability) prevents paint micro-cracking during heavy roll forming.
Technical Specifications:
Standards: GB/T 12754, JIS G 3312, EN 10169, ASTM A755/A755M
Substrate Grades: DX51D+Z, SGCC, CS Type B (Base Zinc: Z40–Z275 g/m²)
Coating Systems: PE (Polyester), SMP (Silicone Modified Polyester), HDP (High Durable Polyester), PVDF (Polyvinylidene Fluoride)
Coating Structure: Top: 15–25 µm (Primer + Finish) | Back: 5–12 µm (Epoxy/Polyester Service Coat)
Supply Range: Thickness: 0.12–1.5 mm | Width: 600–1250 mm
Key Applications:
Commercial warehouse exterior roof/wall sandwich panels, roller shutter doors, cold-room insulated panels, rainwater downspouts, and appliance shells.
